KSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise Control

Product Categories
Zhongshan Vangood Appliances Mfg Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

KSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise Control

Brand Name : Vanka

Certification : ISO9001：2015,CE

Place of Origin : China

MOQ : 50 Sets

Price : $5-$10 Sets

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 20000 Set/Sets per Month

Delivery Time : 30 work days

Packaging Details : 570x340x165

Color : Silver

Gas Type : NG LPG

Rust Resistant : rust resistant for outdoor use

Heating Characterisic : ≥12MV(within20s at 650℃)

Applicable Type : RV, Outdoor, Garage, Household

Pipe Diameter : 60 mm

Installation : Wall Mounted

Model : Greenstar 8000 Life

Advantage : Energy Save

Applocation : Gas Water Heater

Efficiency Rating : 95%

Ignition Wire Length : 30cm

Rated Voltage : 220V

Installation Type : Wall Mount

Warranty : 1 Year

Contact Now


KSD-301 Bimetal Thermostat Switch – Normally Closed Heating Element Controller

The KSD-301 thermostat is a bimetal thermal switch designed for various heating elements and household appliances. The KSD-301 operates through the thermal expansion and contraction of the bimetal disc, achieving mechanical open/close control. It features stable operating temperature, fast response, and a simple yet reliable structure, making it suitable for water heaters, dryers, fan heaters, water dispensers, and other applications requiring temperature control and overheating protection.

Key Features
  • Precise Temperature Control: KSD-301 provides precise operating temperature (±3°C), ensuring stable temperature regulation for equipment.
  • High Load Capacity: KSD-301 supports up to 10A/250VAC load capacity, compatible with most household appliances.
  • Durable & Reliable: KSD-301 adopts high-temperature-resistant bimetal material, offering long service life and high reliability.
  • Compact Design: KSD-301 features a compact structure, easy to install and compatible with multiple mounting options.
  • Mechanical Operation: KSD-301 is a mechanical thermostat that operates without external power, reducing failure risks.
  • Customizable Options: KSD-301 allows customized operating temperatures and supports OEM/ODM services.
Technical Specifications
Item Specification
Model KSD-301
Operating Temperature Range Common: 50°C / 60°C / 70°C / 80°C / 90°C (customizable)
Operating Accuracy ±3°C (typical)
Rated Voltage 250VAC
Rated Current 10A (resistive load)
Contact Type Normally Closed (NC) / Normally Open (NO) optional
Housing Material Epoxy resin encapsulation / Metal case (depending on model)
Connection Type Quick connector / Wire soldering / Pin terminal (optional)
Mechanical Life ≥10,000 cycles (typical)
Working Temperature -10°C ~ +150°C
Mounting Method Clip-on / Screw fixing / Insert type
Applications Water heaters, dryers, coffee machines, heaters, water dispensers, etc.
Frequently Asked Questions

Q1: What is the operating temperature range of the KSD-301 thermostat?
A1: The KSD-301 can be set at common trip points such as 50°C, 60°C, 70°C, 80°C, or 90°C. Customized temperature settings are also available upon request.

Q2: Is the KSD-301 available in both NC and NO types?
A2: Yes, the KSD-301 is available in Normally Closed (NC) and Normally Open (NO) versions to suit different applications.

Q3: How much current can the KSD-301 handle?
A3: The standard model is rated for 10A at 250VAC (resistive load). For inductive loads or higher current, please consult us for suitable models.

Q4: What appliances are suitable for the KSD-301 thermostat?
A4: The KSD-301 is widely used in water heaters, dryers, fan heaters, coffee machines, and water dispensers, as well as other heating devices requiring temperature control and protection.

Q5: Can I request OEM/ODM service for KSD-301?
A5: Yes, OEM/ODM services are supported. We can provide customized temperature settings, housing types, and wiring options according to customer requirements.

KSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise Control
Front View
KSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise Control
Top View
KSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise Control
Installation Example
KSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise Control
Flame Distribution

KSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise ControlKSD-301 Bimetal Thermostat Switch with 220V Rated Voltage 10A Rated Current and 50°C-90°C Operating Temperature for Precise Control
Side View
